Cage crusher is designed according to the principle of impact crushing. It has the characteristics of simple structure, high crushing efficiency, good sealing performance, stable operation, convenient cleaning and maintenance, etc. It is widely used in mining, building materials, chemicals, feed, food, medicine, plastics and other industries. Lane can customize a special cage crusher for you to meet any of your needs.
Cage Crusher |
|||||
|---|---|---|---|---|---|
| Model | Capacity(tph) | Power(kw) | Overall Size(mm) | Input Size(mm) | Output Size(mm) |
| LAC-40L | 1-3 | 5.5*2 | 1430*1400*1200 | 300*500 | Φ200 |
| LAC-60L | 4-6 | 7.5*2 | 1550*1400*1200 | 300*500 | Φ200 |
| LAC-80L | 6-8 | 15*2 | 1720*1500*1200 | 300*500 | Φ200 |
| LAC-100L | 8-10 | 18.5*2 | 1920*1700*1200 | 300*500 | Φ200 |
The material enters the center of the rotating rotor from the inlet, is thrown out by centrifugal force, and violently impacts the high-speed rotating steel rod to achieve the initial crushing.
After the initial crushing, the material continues to move in the rotor. When it is thrown out, it will be hit and sheared by the steel rod rotating in the opposite direction. The material is further crushed and refined, and the particle size is continuously reduced.
The material undergoes multiple collisions and shears in different directions in the rotor until it passes through all the steel rods in each circle. In this process, the material is continuously crushed and finally reaches the required particle size requirements.
The crushed material falls to the bottom of the crusher and is discharged through the discharge port.
If you have a better idea, or would like to do an experimental test as well, please contact us right away!
Waterless crushing
Waterless crushing is one of the outstanding features of the cage crusher, which is especially beneficial for moisture-sensitive materials such as compound fertilizers.
Efficient crushing
The cage crusher adopts a neutral horizontal design and is equipped with sharp rotating blades, which can crush efficiently and thoroughly.
Easy to operate and maintain
The equipment is reasonably designed, easy to operate, with a clear internal structure, easy to clean and replace parts, reducing the difficulty of daily operation and maintenance.
